Technik

Grundriss M2 / Ground Plan M2

Kasino, Bühne, Grundriss / Kasino, stage, groundplan
Kasino, Bühne, Grundriss / Kasino, stage, groundplan
Kasino, Bühne, Schnitt / Kasino, stage, drawn in section
Kasino, Galerie, Grundriss / Kasino, gallery, groundplan
Kasino, obere Ebene / Kasino, upper level
Kasino, Theke, Grundriss / Kasino, bar, groundplan
Kasino, untere Ebene / Kasino, lower level

Cotton Club / Cotton Club
Cotton Club, Grundriss / Cotton Club, groundplan

Schnitt Kasino + Cotton Club / Kasino + Cotton Club, drawn in section
Grundrisse Gebäudekomplex / Building complex, groundplans

Lageplan Nightliner Parkplatz / For Nightliner: groundplan, parking area

Front PA

10x d&b Y8
2x d&b Y12
6 Tops on each side

4x d&b V-Sub
1x d&b J-Infra

3x d&b D80 Amp

Delay

4x d&b E3
2x d&b C6

2x d&b P1200 Amp

Nearfill

2x Nexo PS10
1x Camco D-Power 2 Amp

8x Nexo PS15
6x Crown Amp 1400 SL

Drumfill/Sidefill

2x Nexo PS 10
2x Nexo LS-500 Sub

2x d&b F2 Top
2x d&b B1 Sub

2x d&b F2 Amp
2x d&b B1 Amp
2x Crown Amp 1400 SL

1x Pioneer DJM 900NXS
2x Pioneer CDJ 2000NXS
2x Technics SL- 1210 MKII

Digital

1x Yamaha QL5

Stagebox:
1x Rio3224D - 32 Channel
1x Rio1608D - 16 Channel
2x Cat5e Stage Left-FOH

Analog

1x Yamaha PM 3500
1x 48/6 Multicore + Stagebox
1x 32-Channel-Split for Monitor

Siderack:
1x Lexicon PCM 90
1x Dynacord DRP 20
1x Yamaha SPX 990
1x T.C. D-Two
1x BSS DRP 901 Dual Compressor
4x DBX 166 Dual Compressor
3x Drawner 201 Dual Gate
1x Klark EQ DN 360
1x Sony CD
1x Sony MD

1x Intercom FOH-Stage/Monitor/Follow

Standard

8x Robe DL4X LED Spot
8x Robe Robin 800 LED Wash
12x Robe Parfect 100 LED Pars
8x Robe Parfect 100 SW LED Pars
4x 4 Lite Blinder
1x 2kW Follow-Spot
1x Unique 2.0 Hazer
2x DMX Splitter

1x MA GrandMA 2 Light

Lightcatwalk

10m distance to Stage

8x ETC Source Four Series 2 LED
Lustr. Profiler

6x ETC Source Four Series HD LED
Daylight Fresnel

BGV C1 traverse rigg over stage
BGV D8+ fronttraverse

Additional Equipment:

2x Martin Atomic 3000 Strobe
10x Involight SonicWave LED Bars
4x Ignition LED Par 64
1x Unique Hazer
1x Fogmachine

Stage Size: 10mx6m
Height: 1m
Clearance: 4,5m

Capacity:

Seating: 500
Without Seating: 1050

Stage Left:

1x 63A CEE
1x 32A CEE
1x 16A CEE

Stage Right:

2x 63A CEE
3x 32A CEE
2X 16A CEE
10x 16A Schuko

Um sich das technische Datenblatt des Kasinos im PDF-Format herunterzuladen, klicken Sie bitte hier.

4x KMT Max 15
4x d&b Mon 15

3x d&b Amp

Drumfill/Sidefill
2x Nexo PS 15
2x Nexo LS-500 Sub

4x d&b C4 Top
4x d&b C4 Sub
2x d&b B1 Sub

4x d&b P1200 Amp

1x Pioneer DJM 900NXS
2x Pioneer CDJ 2000NXS
2x Technics SL- 1210 MKII

Stage Size: 8mx5,5m
Height: 0,4m
Clearance: ca. 2,6m

Capacity:
Seating: 150
Without Seating: 350

1x 63A CEE
2x 32A CEE
1x 16A CEE

1x Yamaha QL5 or Yamaha LS9-32
Stagebox:
1x Rio3224D - 32 Channel
1x Rio1608D - 16 Channel
2x Cat5e Stage-FOH
1x 32/8 Multicore

1x 32-Channel-Split for Monitor

1x Intercom FOH-Stage/Monitor/Follow

Standard

12x Litecraft AT 10 LED Pars
6x Robe Robin 100 LED Beam
4x Arri LED Fresnel
4x ETC Source Four 2 LED Profiler
4x Ignition LED Par 64
2x 4 Lite Blinder
1x Unique Hazer
1x DMX Splitter

1x MA GrandMA 2 onPC Tourpack
(inkl. Faderwing)

Additional Equipment:
1x Hazer

Um sich das technische Datenblatt des Cotton Clubs im PDF-Format herunterzuladen, klicken Sie bitte hier.
